VSD Series Drives User Manual
Catalog Number Selection

Table 5-1: VSD Series IntelliPass/IntelliDisconnect Drives Selection Chart

Base Product
Horsepower (VT)
Voltage
Enclosure Rating
Enclosure Style
Revision #
Separator (–)
Communications
Option 1
Option 2
All horsepower ratings are Variable Torque (VT).
1 – 30 hp 208/230V AC; 1 – 75 hp 480V AC
N2/XT Communications selectable on drive keypad.
SA = Sensor Actuator Bus for FEC Interface.
Options List: 00 = None
Note: All VSD Series IntelliPass Drives incorporate two factory installed Auxiliary Contacts (formerly the "K9" option).
5-2
Code Number
VS = Variable Speed
Drive Prefix
001 = 1.0 hp to
075 = 75 hp
1 = 208V
2 = 230V
4 = 480V
1 = TYPE 1
1 = IntelliPass
4 = IntelliDisconnect
A = Rev 1 (Americas)
0 = None
N = N2/XT/SA Bus Comm (N2 by default)
L = L W Network
®
ON ORKS
See Options List
See Options List
P6 = 3rd Contactor Drive Isolation (IntelliPass only)
For more information visit: www.johnsoncontrols.com
V S 1
Eaton Technology
Powered by
November 2009
1 A - N
LIT-1201828
