Table 13-4: Output Signals — M1 ➔ G1.3, continued
Code Parameter
P1.3.14 Act.Sp. Supv Fct 0
P1.3.15 Act.Sp. Supv Lim 0.0
P1.3.16 Torque Supv Fct 0
P1.3.17 Torque Supv Lim 0.0
P1.3.18 TempLim Supv
Fct
P1.3.19 TempLim Supv
Lim
P1.3.20 StartRlyON-Del.
P1.3.21 StartRlyOFF-Del. 0.0
Drive Control Parameters — M1 ➔ G1.4
Table 13-5: Drive Control Parameters — M1 ➔ G1.4
Code Parameter
P1.4.1 Start Mode
P1.4.2 Stop Mode
P1.4.3 Brake Chopper
P1.4.4 S-curve Time
13-10
Min. Max.
2
100.0
2
300.0
0 2
-50 170
0.0 100.0
100.0
Min. Max.
0 1
0 1
0 4
0.0 10.0
For more information visit: www.johnsoncontrols.com
ID
Unit Default Number Description
0 314
% 0.0 315
0 316
% 0.0 317
0 318
°F 104 319
s 0.0 320
s 0.0 321
ID
Unit Default Number Description
0 401
1 402
0 403
s 0.0 404
Eaton Technology
Powered by
November 2009
Actual Speed Supervision
Function:
0 = Not used
1 = Low limit
2 = High limit
Actual Speed Supervision Value.
(±1.0% hysteresis)
Torque Limit Supervision
Function:
0 = Not used
1 = Low limit
2 = High limit
Torque Limit Supervision Value
Temperature Limit Supervision
Function:
0 = Not used
1 = Low limit
2 = High limit
Temperature Limit Supervision
value
Relay/Digital output ON-delay
time after start-command is
given.
Relay/Digital output OFF-delay
time after stop-command is
given.
0 = Ramp
1 = Flying start
0 = Coasting
1 = Ramp
Brake Chopper Mode Selection.
0 = Brake NO, Test NO
1 = Brake YES(Run), Test YES
(Ready+run)
2 = Brake chopper EXTERNAL,
Test NO
3 = Brake YES(Ready+run), Test
YES (Ready+run)
4 = Brake YES(Run), Test NO
Smooth ratio for S-curve
