VSD Series Drives User Manual
Table 12-3: Input Signals — M1 ➔ G1.2, continued
Code Parameter
P1.2.6 (A) DI-3 Funct.
P1.2.7 (A) DI-4 Funct.
12-6
Min. Max.
0 17
0 17
For more information visit: www.johnsoncontrols.com
ID
Unit Default Number Description
13 205
8 206
Eaton Technology
Powered by
November 2009
Default #13 Interlock/Run Enable
0 = Not Used
1 = Ext. fault, closing contact
2 = External fault, opening
contact
3 = Fault reset
4 = Run enable-Closed Contact
5 = Force ctrl. place to Hand
6 = Force ctrl. place to Auto
7 = Reverse
8 = Speed Select 1
9 = Fire Mode-Closed Contact
10 = Speed Select 2
11 = Speed Select 3
12 = Force Bypass
13 = External interlock closed
14 = External interlock open
15 = Mot. Pot. UP
16 = Mot. Pot. DOWN
17 = Fire Mode-Open Contact
Default #8 Speed Select 1
0 = Not Used
1 = Ext. fault, closing contact
2 = External fault, opening
contact
3 = Fault reset
4 = Run enable-Closed Contact
5 = Force ctrl. place to Hand
6 = Force ctrl. place to Auto
7 = Reverse
8 = Speed Select 1
9 = Fire Mode-Closed Contact
10 = Speed Select 2
11 = Speed Select 3
12 = Force Bypass
13 = External interlock closed
14 = External interlock open
15 = Mot. Pot. UP
16 = Mot. Pot. DOWN
17 = Fire Mode-Open Contact
