Input Signals — M1 ➔ G1.2
Table 10-3: Input Signals — M1 ➔ G1.2
Code Parameter
P1.2.1 Start Mode
P1.2.2 Intlk Stop Mode
P1.2.3 Intlk Timeout
P1.2.4 Start Delay Time 0.00
P1.2.5 (A) DI-2 Funct.
CAUTION
Unattended start will occur if power
is supplied with Start Command
activated.
LIT-1201828
Min. Max.
0 3
0 1
0.00 300.00
300.00
0 17
For more information visit: www.johnsoncontrols.com
ID
Unit Default Number Description
1 201
1 216
s 5.00 202
s 5.00 203
1 204
VSD Series Drives User Manual
Start Function:
0 = Normal start without
interlockings.
1 = Interlocked start. One of the
digital inputs must be
programmed to Intlk/RunEna.
DI-3 is defaulted for this feature.
2 = Mode 1 + timeout
supervision. If the interlock is not
OK within the interlock timeout
time, start request is ignored and
must be given again.
3 = Delayed start. Start request is
given after delay time has expired.
0 = Coasting
1 = Ramp
Interlock timeout time for Start
Function #2.
Default = 5s.
Start delay time for Start
Function #3.
Default = 5s.
Default #1 External Fault Close
0 = Stop pulse, when 3-wire
start/stop logic is selected.
(False=Stop, True=Ready to Run)
1 = Ext. fault, closing contact
2 = External fault, opening contact
3 = Fault reset
4 = Run enable-Closed Contact
5 = Force ctrl. place to Hand
6 = Force ctrl. place to Auto
7 = Reverse
8 = Speed Select 1
9 = Fire Mode-Closed Contact
10 = Speed Select 2
11 = Speed Select 3
12 = Force Bypass
13 = External interlock closed
14 = External interlock open
15 = Mot. Pot. UP
16 = Mot. Pot. DOWN
17 = Fire Mode-Open Contact
10-5
