Getting Started Guide
VFD67
AC variable frequency drive
for 3 phase induction
motors from 0.25kW to
7.5kW, 0.33hp to 10hp
Model sizes A, B, C and D
Part Number: 24-10511-23
Issue: 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VFD67 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Johnson Controls VFD67 Series

Summary of Contents for Johnson Controls VFD67 Series

  • Page 1 Getting Started Guide VFD67 AC variable frequency drive for 3 phase induction motors from 0.25kW to 7.5kW, 0.33hp to 10hp Model sizes A, B, C and D Part Number: 24-10511-23 Issue: 1...
  • Page 2 General Information The manufacturer accepts no liability for any consequences resulting from inappropriate, negligent or incorrect installation or adjustment of the optional parameters of the equipment or from mismatching the variable speed drive with the motor. The contents of this guide are believed to be correct at the time of printing. In the interests of commitment to a policy of continuous development and improvement, the manufacturer reserves the right to change the specification of the product or its performance, or the content of the guide without notice.

  • Page 3: Table Of Contents

    Contents EC Declaration of Conformity ..........4 Safety Information .............. 5 Warnings, Cautions and Notes ............... 5 Electrical Safety - general warning ............5 System design and safety of personnel ..........5 Environmental Limits ................5 Access ..................... 6 Compliance and regulations ..............6 Motor .......................

  • Page 4: Ec Declaration Of Conformity

    Directives. The Technical documentation can by the surveillance Authorities be requested at the following address: Company: Johnson Controls Inc. - Att: Environment and Legislation Address, City: Christian X’s Vej 201, 8270 Hoejbjerg Country:...

  • Page 5: Safety Information

    Safety Information Warnings, Cautions and Notes A Warning contains information, which is essential for avoiding a safety hazard. WARNING A Caution contains information, which is necessary for avoiding a risk of damage to the product or other equipment. CAUTION A Note contains information, which helps to ensure correct operation of the product. NOTE Electrical Safety - general warning The voltages used in the drive can cause severe electrical shock and/or burns, and...

  • Page 6: Access

    Access Access must be restricted to authorized personnel only. Safety regulations which apply at the place of use must be complied with. The IP (Ingress Protection) rating of the drive is installation dependant. Compliance and regulations The installer is responsible for complying with all relevant regulations, such as national wiring regulations, accident prevention regulations and electromagnetic compatibility (EMC) regulations.
  • Page 7 If the drive has failed in a manner that causes the display to go blank immediately, it is possible the capacitors will not be discharged. In this case, consult Johnson Controls Inc or their authorized distributor.
  • Page 8 Risk of electrical shock The VFD67 drive remains electrically charged for a period of time after the power is removed. To avoid possible electrical shock, wait at least 10 minutes after AC supply power has been disconnected from the VFD67 drive before servicing the control. Failure WARNING to wait until the VFD67 drive fully discharges could cause electrical shock, personal injury, or death.

  • Page 9: Rating Data

    Rating Data Figure 2-1 Model code explanation (Size A to D) VFD67 Frame size / Enclosure: A = 6.1 x 3 x 5.7in, NEMA 1 B = 8.1 x 3.4 x 6.2in, NEMA 1 C = 10.2 x 4 x 6.8in, NEMA 1 D = 13.2 x 4.5 x 7.9in, NEMA 1 Nominal motor rating (hp): A = 0.33...
  • Page 10 Table 2-4 VFD67, 3 phase, 380 to 480VAC ±10%, 48 to 62Hz units 100% RMS 150% overload Input Typical full Maximum Minimum Nominal output current for 60s fuse load input continuous braking Model motor power current rating current input current resistor value Number Ω...

  • Page 11: Mechanical Installation

    Mechanical Installation Enclosure The drive is intended to be mounted in an enclosure which prevents access except by trained and authorized personnel, and which prevents the ingress of contamination. It is WARNING designed for use in an environment classified as pollution degree 2 in accordance with IEC 60664-1.
  • Page 12 Figure 3-2 Minimum mounting clearances Drive size B (≤0.75kW) 0.39* B (≥1.1kW) or B (110V) 0.39 3.94 1.97* *This is the minimum spacing between drives at the base of the drive where it is mounted against a back plate. Figure 3-3 Features of the drive (size B illustrated) Display SmartStick slot...

  • Page 13: Electrical Installation

    Electrical Installation Power terminal connections Figure 4-1 Size A power terminal connections Internal EMC filter L1 L2/N PE** Optional Braking Optional resistor EMC filter Thermal Optional Supply protection line reactor ground device Stop Start/ Reset Optional ground connection Mains supply Figure 4-2 Sizes B, C and D power terminal connections L3/N Internal...

  • Page 14: Ground Leakage

    On the VFD67 size D, the internal EMC filter is connected to the -DC Bus. NOTE The braking terminals are not available on the size A 110V drive. NOTE Fuses/MCB The AC supply to the drive must be installed with suitable protection against overload and short circuits.

  • Page 15: Emc

    3 phase 200V drives 8mA AC at 230V, 50Hz (proportional to supply voltage and frequency) 3 phase 400V drives 8.2mA AC at 415V, 50Hz (proportional to supply voltage and frequency) Size D 1 phase 200V drives 20.5mA AC at 230V, 50Hz (proportional to supply voltage and frequency) 3 phase 200V drives 8mA AC at 230V, 50Hz (proportional to supply voltage and frequency) 3 phase 400V drives...

  • Page 16: Control Terminals I/O Specification

    W) need to be fed twice through a ferrite ring (provided with the drive), so that the drive meets the requirements of operating in the second environment. 4.3.2 Removing the internal EMC filter Figure 4-3 Removal and re-fitting of internal EMC filter Internal EMC filter Tab fully inserted:...
  • Page 17 The analog inputs are unipolar. NOTE 0V common Analog input 1 (A1), either voltage or current (see Pr 16) Voltage: Current input 0 to 10V / mA as parameter range Parameter range 4-20, 20-4, 0-20, 20-0, 4-.20, 20-.4, VoLt Input range automatically scaled to Pr 01 Minimum set Scaling speed / Pr 02 Maximum set speed Input impedance...
  • Page 18 Analog voltage output - Motor speed Voltage output 0 to +10V 0V represents 0Hz/rpm output Scaling +10V represents the value in Pr 02 Maximum set speed Maximum output current Resolution 0.1% +24V output Maximum output current 100mA Digital output - User selectable Pr 35 Voltage range 0 to +24V Maximum output current...

  • Page 19: Keypad And Display

    Keypad and Display The keypad and display are used for the following: • Displaying the operating status of the drive • Displaying a fault or trip code • Reading and changing parameter values • Stopping, starting and resetting the drive Figure 5-1 Keypad and display on the display indicates if motor map 1 or 2 is selected.

  • Page 20: Selecting And Changing Parameters

    Selecting and changing parameters This procedure is written from the first power up of the drive and assumes no terminals NOTE have been connected, no parameters have been changed and no security has been set. Figure 5-2 STATUS MODE Press and hold for 2s Hold for 2s...

  • Page 21: Saving Parameters

    Status Modes Left hand Status Explanation display The drive is enabled and ready for a start command. The Drive ready output bridge is inactive. The drive is inhibited because there is no enable command, Drive inhibited or a coast to stop is in progress or the drive is inhibited during a trip reset.

  • Page 22: Security Codes

    Unlock security as described above. • Set Pr 25 to 0 • Press the MODE key. If a security code has been lost or forgotten, please contact Johnson Controls Inc. NOTE Setting drive back to default values • Set Pr 10 to L2 •...

  • Page 23: Parameters

    Parameters Parameters are grouped together into appropriate subsets as follows: Level 1 Pr 01 to Pr 10: Basic drive set-up parameters Level 2 Pr 11 to Pr 12: Drive operation set-up parameters Pr 15 to Pr 21: Reference parameters Pr 22 to Pr 29: Display / keypad configuration Pr 30 to Pr 33: System configuration Pr 34 to Pr 36: Drive user I/O configuration Pr 37 to Pr 42: Motor configuration (non-standard set-up)
  • Page 24 Function Range Defaults Type AI.AV, AV.Pr, AI.Pr, Pr, PAd, Drive configuration E.Pot, tor, Pid, HVAC The setting of Pr 05 automatically sets up the drives configuration. A change to Pr 05 is set by pressing the MODE key on exit from parameter edit mode. NOTE The drive must be disabled, stopped or tripped for a change to take place.
  • Page 25 Figure 6-2 Pr 05 = AV.Pr (voltage input and 3 presets) Local voltage speed reference input (A1) (2kmin) +10V reference output Reference select Analog output (motor speed) +24V output Digital output (zero speed) /Stop Reference select Reference selected Preset 2 Preset 3 Preset 4 Figure 6-3 Pr 05 = AI.Pr (current input and 3 presets)
  • Page 26 Figure 6-4 Pr 05 = Pr (4 presets) Not used +10V reference output Reference select Analog output (motor speed) +24V output Digital output (zero speed) /Stop Reference select Reference selected Preset 1 Preset 2 Preset 3 Preset 4 Figure 6-5 Pr 05 = PAd (keypad control) Not used +10V reference output Not used...
  • Page 27 Figure 6-6 Pr 05 = E.Pot (binary control - increase / decrease speed) Not used +10V reference output Down Analog output (motor speed) +24V output Digital output (zero speed) /Stop When Pr 05 is set to E.Pot, the following parameters are made available for adjustment: •...
  • Page 28 When torque mode is selected and the drive is connected to an unloaded motor, the motor speed may increase rapidly to the maximum speed (Pr 02 +20%) WARNING Figure 6-8 Pr 05 = Pid (proportional integral and direction control) 4-20mA PID PID feedback input feedback input +10V reference output...
  • Page 29 Figure 6-10 Pr 05 = HVAC terminal configuration Remote speed Remote current speed reference input reference input (A1) +10V reference output Not used Analog output (motor speed) +24V output Digital output (zero speed) Drive enable / reset Run forward Auto H: Contacts made in 'hand' position - Run reverse Keypad control...

  • Page 30: Parameter Descriptions - Level 2

    Function Range Defaults Type Motor power factor 0 to 1 0.85 Enter the motor rated power factor cos ϕ (taken from the motor name plate). The power factor value could be automatically changed after a rotating autotune. See Pr 38 on page 35. NOTE Function Range...
  • Page 31 Great care should be taken when implementing a brake control set-up, as this may cause a safety issue depending on the application, e.g. crane. If in doubt, contact the supplier of the drive for further information. WARNING Ensure that the brake controller is setup correctly before the electro-mechanical brake circuit is connected to the drive.
  • Page 32 Function Range Defaults Type Load display units Ld, A Ld: Active current as a % of motor rated active current A: Drive output current per phase in Amps Function Range Defaults Type Speed display units Fr, SP, Cd Fr: Drive output frequency in Hz SP: Motor speed in rpm Cd: Machine speed in customer defined units (See Pr 24).
  • Page 33 Before the SmartStick is written to using Prog, the SmartStick will need to be inserted NOTE into the drive at power up or a reset command performed when the drive has been powered up, otherwise will trip on C.dAt when Prog command executed. For best motor performance, an autotune should be carried out after parameter copying NOTE has taken place.
  • Page 34 Function Range Defaults Type Dynamic V to f select OFF or On OFF:Fixed linear voltage to frequency ratio (constant torque - standard load) On: Voltage to frequency ratio dependant on load current (dynamic/variable torque/ load). This gives a higher motor efficiency. Function Range Defaults...
  • Page 35 Function Range Defaults Type Analog output control (terminal B1) Fr, Ld, A, Por, USEr Voltage proportional to motor speed Voltage proportional to motor load Voltage proportional to output current Por: Voltage proportional to output power USEr: User programmable A change to Pr 36 is set by pressing the MODE key on exit from parameter edit mode.
  • Page 36 Set for a 4 pole motor Set for a 6 pole motor Set for an 8 pole motor Function Range Defaults Type Voltage mode select Ur S, Ur, Fd, Ur A, Ur l, SrE Ur S: Stator resistance is measured each time the drive is enabled and run No measurement is taken Fixed boost Ur A:...
  • Page 37 Function Range Defaults Type Brake release frequency 0.0 to 20.0 Hz Brake apply frequency Defines the brake release and brake apply frequencies. If the current is >Pr 46 and the frequency is > Pr 48, the brake release sequence is started.

  • Page 38: Parameter Descriptions - Level 3

    Figure 6-13 Brake sequence Brake Brake apply release frequency Output frequency frequency : Brake release current threshold Brake apply Output current current threshold Brake release Ramp hold Pre brake Post brake release delay release delay Function Range Defaults Type Last trip Trip before Pr 55 Trip before Pr 56 Trip before Pr 57...

  • Page 39: Diagnostic Parameters

    Diagnostic parameters The following read only (RO) parameters can be used as an aid to fault diagnosis on the drive. See Figure 8-1 Diagnostics logic diagram on page 46. Function Range Type Frequency reference selected ±Pr 02 Hz Pre-ramp reference ±Pr 02 Hz Post-ramp reference ±Pr 02 Hz...

  • Page 40: Quick Start Commissioning

    Quick Start Commissioning This procedure is written from default parameter settings as the drive would be delivered from the factory. Keypad control Figure 7-1 Minimum required control terminal connections Not used +10V reference output Not used Analog output (motor speed) +24V output Digital output (zero speed)
  • Page 41 Action Detail Ensure: • The drive enable signal is not given, terminal B4 is open Before power up • The motor is connected to the drive The motor connection is correct for the drive Δ or Y • • The correct supply voltage is connected to the drive Ensure: Power up the drive...

  • Page 42: Terminal Control

    Terminal control Figure 7-2 Minimum required control terminal connections Remote current speed reference input (A1) +10V reference output Local voltage speed reference input (A2) (2kmin) Speed Analog output potentiometer (motor speed) +24V output Digital output (zero speed) /Stop Local (A2)/Remote (A1) speed reference select Terminal B7 open: Local voltage speed reference (A2) selected VFD67 Size A to D Getting Started Guide...
  • Page 43 Action Detail Ensure: • The drive enable signal is not given, terminal B4 is open • The run signal is not given, terminal B5/B6 is open Before power up • The motor is connected to the drive The motor connection is correct for the drive Δ or Y •...

  • Page 44: Diagnostics

    Diagnostics Do not attempt to carry out internal repairs. Return a faulty drive to the supplier for repair. WARNING Trip code Condition Possible cause Low AC supply voltage DC bus under voltage Low DC bus voltage when supplied by an external DC power supply Deceleration rate set too fast for the inertia of the machine DC bus over voltage Mechanical load driving the motor...
  • Page 45 * The Enable/Reset terminal will not reset an O.Ld1 trip. Use the Stop/Reset key. ** These trips cannot be reset for 10 seconds after they occur. For a detailed description of how to reset the drive after it has tripped, contact the supplier of the drive.
  • Page 46 Figure 8-1 Diagnostics logic diagram Speed clamps Ramps Minimum Analog inputs Acceleration speed rate Analog input 1 (%) Maximum Frequency Deceleration speed reference rate selected (Hz) Ramp mode select Analog input 2 (%) Pre-ramp reference (Hz) reference Post-ramp reference Digital I/O (Hz) selected Motor...

  • Page 47: Parameter List

    Parameter List Description Default Setting 1 Setting 2 Level 1 parameters Minimum set speed (Hz) Maximum set speed (Hz) 60.0 Acceleration rate (s/100Hz) Deceleration rate (s/100Hz) Drive configuration Motor rated current (A) Drive rating Motor rated speed (rpm) 1800 Motor rated voltage (V) 230 / 460 Motor power factor (cos ϕ) 0.85...
  • Page 48 Description Default Setting 1 Setting 2 Brake apply frequency (Hz) Pre-brake release delay (s) Post brake release delay (s) Last trip Trip before Pr 55 Trip before Pr 56 Trip before Pr 57 Configurable parameter 1 Configurable parameter 2 Configurable parameter 3 Configurable parameter 4 Configurable parameter 5 Configurable parameter 6...

  • Page 49: Technical Specifications

    Technical specifications Model VFD67 Drive voltage rating 110Vac, 230Vac, 460Vac @ 60Hz (110Vac, 230Vac, 400Vac @ 50Hz) Output Voltage/Output 230 Vac, 460Vac @ 60Hz (230Vac, 400Vac @ 50Hz) frequency Switching frequency 3kHz, 6kHz, 12kHz, 18kHz Duty Heavy Overload limit 150% overload current for 60s Acceleration/Deceleration 0 to 3200.0 s/100Hz Start/Stop...

  • Page 50: Ul Listing Information

    UL Listing Information Table 11-1 Approvals CE approval Europe C Tick approval Australia UL / cUL approval USA & Canada 11.1 UL information (for VFD67 size A, B, C and D) The JCI UL file number is E244421. Confirmation of UL listing can be found on the UL website: www.ul.com.
  • Page 52 24-10511-23...
