VSD Series Drives User Manual
Tables 13-8: Protections — M1 ➔ G1.7, continued
Code Parameter
P1.7.15 Underload
Protection
P1.7.16 UP fnom Torque 10.0
P1.7.17 UP f0 Torque
P1.7.18 UP Time Limit
P1.7.19 Autom. Restart
P1.7.20 Fire Mode Speed 0
Fieldbus Parameters — M1 ➔ G1.8
Table 13-9: Fieldbus Parameters — M1 ➔ G1.8
Code Parameter
P1.8.1 FB Data Out1 Sel 0
P1.8.2 FB Data Out2 Sel 0
P1.8.3 FB Data Out3 Sel 0
P1.8.4 FB Data Out4 Sel 0
P1.8.5 FB Data Out5 Sel 0
ID number of parameter or variable to be sent over fieldbus. ID 1 – 20 are Monitoring values, Menu 7 (M7). See Table 13-13.
13-14
Min. Max.
0 3
150.00
5.0 150.00
2.00 600.00
0 3
100.0
Min. Max.
10000
10000
10000
10000
10000
For more information visit: www.johnsoncontrols.com
ID
Unit Default Number Description
0 716
% 50.0 717
% 10.0 718
s 20.00 719
0 706
% 100 804
ID
Unit Default Number Description
1 1001
5 1002
8 1003
7 1004
9 1005
Eaton Technology
Powered by
November 2009
0 = No response
1 = Warning
2 = Fault, stop mode after fault
according to ID402
3 = Fault, stop mode after fault
always by coasting
Minimum torque allowed when
above FWP.
Minimum torque allowed with
zero frequency.
Resets faults. See Page 15-20.
0 = Disabled
1 = Automatically transferred to
Bypass
2 = Reset drive only
3 = Reset drive, if fails,
transferred to Bypass
When fire mode input is
triggered, drive will run at fire
mode speed.
Fieldbus process data output 1
selection.
Default = Actual Speed
Fieldbus process data output 2
selection.
Default = Motor Current
Fieldbus process data output 3
selection.
Default = Motor Voltage
Fieldbus process data output 4
selection.
Default = Motor Power
Fieldbus process data output 5
selection.
Default = DC-Link Voltage
LIT-1201828
