Multimonitor (G7.25)
This parameter allows the viewing and selection (if allowed by System menu item, P5.5.4) of
three simultaneously monitored items from the Monitored Menu Items shown in Table 6-13.
Use the right arrow key to select the item to be modified and then the up or down arrow keys
to select the new item. Press the ENTER key to accept the change.
Operate Menu (M8)
The Operate Menu provides a easy to use method of viewing key numerical Monitoring
Menu items. Some applications also support the setting of reference values in this menu. The
items displayed vary by application. Table 6-14 is an example for the Generic PI application.
Table 6-14: Operate Menu Items — Generic PI Application Example
Index
O1
O2
O3
O4
O5
O6
O7
O8
O9
O10
O11
O12
O13
O14
O15
O16
Units will vary depending on active application.
Not available in Remote Input application.
LIT-1201828
Figure 6-11: Digital Inputs — DI-4, DI-5, DI-6 Status
Figure 6-12: Digital and Relay Outputs — DO-1, RO-1, RO-2 Status
Signal Name Unit

Output Frequency

Hz
Actual Speed %

Speed Setpoint

%

Motor Speed

rpm

Motor Current

A

Motor Torque

%

Motor Power

%
Motor Voltage V
DC-Bus Voltage V

Unit Temperature

°F

Motor Temperature

%
PI-Setpoint %
PI-Input %
PI-Error Value %
PI-Output %
Multimonitor
For more information visit: www.johnsoncontrols.com
V1.15
DI-4, DI-5, DI-6
ON OFF OFF
V1.16
DO-1, RO-1, RO-2
OFF OFF ON
Description
Actual motor frequency
Actual motor speed between min and max frequency
Speed Setpoint (Can be Keypad on AI-1/AI-2)
Actual motor speed
Measured Motor Current
Calculated Motor Torque
Calculated Motor Power
Measured Motor Voltage
Measured DC-Bus Voltage
Heatsink temperature
Calculated motor temperature based on the motor
nameplate information and actual motor load
PI Setpoint
PI Input (measured) value
Calculated error between PI actual and reference values
PI output (speed reference when PI active)
Displays three values simultaneously
