Motor Control Parameters — M1 ➔ G1.6
Table 12-7: Motor Control Parameters — M1 ➔ G1.6
Code Parameter
P1.6.1 Motor Ctrl Mode 0
P1.6.2 V/Hz Optim.
P1.6.3 V/Hz Ratio
P1.6.4 Field WeakngPnt 8.00
P1.6.5 Voltage at FWP
P1.6.6 V/Hz Mid Freq
P1.6.7 V/Hz Mid Voltg
P1.6.8 Zero Freq Voltg
P1.6.9 Switching Freq
P1.6.10 Overvolt Contr
P1.6.11 Undervolt Contr
P1.6.12 Identification
12-12
Min. Max.
1
0 1
0 3
320.00
10.00 200.00
0.00 Field
Weakening
Point
0.00 100.00
0.00 40.00
1.0 Switching
FreqMax
0 2
0 1
0 2
For more information visit: www.johnsoncontrols.com
ID
Unit Default Number Description
0 601
0 602
0 603
Hz 60.00 604
% 100.00 605
Hz 60.00 606
% 100.00 607
% 0.00 608
kHz 3.6 609
1 610
1 611
0 612
Eaton Technology
Powered by
November 2009
Motor control mode:
0 = frequency control
1 = speed control
V/F optimization selection:
0 = none
1 = automatic torque boost
V/F ratio selection:
0 = linear
1 = squared
2 = programmable
3 = Linear with flux optim.
Field weakening point.
Motor voltage
(%*MotorNPVoltage) at field
weakening point.
Programmable V/Hz curve
middle point frequency.
Motor voltage
(%*MotorNPVoltage) at
programmable V/Hz curve
middle point.
Motor voltage
(%*MotorNPVoltage) at zero speed.
Switching frequency in kHz.
See Appendix A, Table A-1.
0 = Off
1 = On with no ramping
2 = On with ramping
0 = Off
1 = On
Identification run. When this
parameter is set greater than
zero, then start command must
be given within 20 seconds.
