VSD Series Drives User Manual
Table 9-3: Input Signals — M1 ➔ G1.2, continued
Code Parameter
P1.2.16 StPt. Scale Max
P1.2.17 MotPotStPt
Memory
Output Signals — M1 ➔ G1.3
Table 9-4: Output Signals — M1 ➔ G1.3
Code Parameter
P1.3.1 (A) AO-1 Funct.
P1.3.2 (A) AO-1 Filter
P1.3.3 (A) AO-1 Invert
P1.3.4 (A) AO-1 Min.
P1.3.5 (A) AO-1 Scale
9-8
Min. Max.
0.0 100.0
0 1
Min. Max.
0 8
0.00 10.00
0 1
0 1
10 1000
For more information visit: www.johnsoncontrols.com
ID
Unit Default Number Description
% 0.0 215
0 221
ID
Unit Default Number Description
1 301
s 1.00 302
0 303
0 304
% 100 305
Eaton Technology
Powered by
November 2009
Speed that corresponds to the
maximum setpoint signal.
0.0%=NOT IN USE!
Parameter to select reset
function for motor
potentiometer speed setpoint.
Default: No reset.
Analog output function:
0 = Fieldbus controlled
1 = O/P frequency (0 - f max )
2 = Reference frequency
(0 - f max)
3 = Motor speed (0 - 100% x
Motor nom. speed)
4 = O/P current
(0 - 100% x I nMot)
5 = Motor torque
(0 - 100% x T nMot)
6 = Motor power
(0 - 100% x P nMot)
7 = Motor voltage
(0 - 100% x U nMot)
8 = DC-Bus Voltage
(0 - 100% x U nMot)
0 = Not inverted
1 = Inverted
0 = 0 mA
1 = 4 mA
