VSD Series Drives User Manual
System Menu Parameters
Language
Selection
Application
Selection
System Menu Copy Parameter Options (S5.3)
The parameter copy function is used when the operator wants to copy one or all parameter
groups from one drive to another. All the parameter groups are first uploaded to the keypad,
then the keypad is connected to another drive and then the parameter groups are
downloaded to it (or possibly back to the same drive).
Note: Before any parameters can successfully be copied from one drive to another, the drive
must be stopped when the parameters are downloaded to it.
S5.3.1
Parameter
S5.3.2
Upload to
Keypad
S5.3.3
Download
from Keypad
6-12
S5.1 Range: English (Spanish , French , Portuguese )
Language
This parameter offers the ability to control the drive through the keypad in the
language of your choice. Currently available language: English.
Available in the future.
S5.2
Application
This parameter sets the active application.
When changing applications, you will be asked if you want the parameters of the
new application to be uploaded to the keypad. If you wish to load the new
application parameters, push the ENTER button. Pushing any other button saves the
parameters of the previously used application in the keypad.
Range: 0 – 4
Parameter Sets
Sets
This parameter allows you to reload the factory default parameter values, and to
store and load two customized parameter sets.
0 Load Factory defaults
1 Store Set 1
2 Load Set 1
3 Store Set 2
4 Load Set 2
Up to keypad
This function uploads all existing parameter groups to the keypad.
Range: 0 – 3
Down from keypad
This function downloads one or all parameter groups from the keypad to the drive.
0 All parameters
1 All, no motor
2 Application parameters
For more information visit: www.johnsoncontrols.com
Eaton Technology
Powered by
November 2009
Default: English
Default: Remote Input
Default: 0 (All parameters)
