Table 9-3: Input Signals — M1 ➔ G1.2, continued
Code Parameter
P1.2.8 (A) DI-5 Funct.
P1.2.9 (A) DI-6 Funct.
P1.2.10 (A) AI-1 Invert
P1.2.11 (A) AI-1 Filter
P1.2.12 (A) AI-2 Range
P1.2.13 (A) AI-2 Invert
P1.2.14 (A) AI-2 Filter
P1.2.15 StPt. Scale Min
LIT-1201828
Min. Max.
0 17
0 17
0 1
0.00 10.00
0 1
0 1
0.00 10.00
0.0 100.0
For more information visit: www.johnsoncontrols.com
ID
Unit Default Number Description
9 207
0 208
0 209
s 0.10 210
1 211
0 212
s 0.10 213
% 0.0 214
VSD Series Drives User Manual
Default #9 Fire-Mode
0 = Not Used
1 = Ext. fault, closing contact
2 = External fault, opening
contact
3 = Fault reset
4 = Run enable-Closed Contact
5 = Force ctrl. place to Hand
6 = Force ctrl. place to Auto
7 = Reverse
8 = Speed Select 1
9 = Fire Mode-Closed Contact
10 = Speed Select 2
11 = Speed Select 3
12 = Force Bypass
13 = External interlock closed
14 = External interlock open
15 = Mot. Pot. UP
16 = Mot. Pot. DOWN
17 = Fire Mode-Open Contact
Default #0 Overload Fault
Relay-input
0 = Overload Fault Relay input.
(Used in Intellipass)
1 = Ext. fault, closing contact
2 = External fault, opening
contact
3 = Fault reset
4 = Run enable-Closed Contact
5 = Force ctrl. place to Hand
6 = Force ctrl. place to Auto
7 = Reverse
8 = Speed Select 1
9 = Fire Mode-Closed Contact
10 = Speed Select 2
11 = Speed Select 3
12 = Force Bypass
13 = External interlock closed
14 = External interlock open
15 = Mot. Pot. UP
16 = Mot. Pot. DOWN
17 = Fire Mode-Open Contact
0 = Not inverted
1 = Inverted
0 = No filtering
Default =1 (4-20mA) (0 – 100%)
0 = 0 - 20 mA
1 = 4 - 20 mA
0 = Not inverted
1 = Inverted
0 = No filtering
Speed that corresponds to the
minimum setpoint signal.
