2.
1
Operate the VFD67 drive from the keypad
Keypad mode is used to operate the drive completely from the keypad. This is the default setting of the VFD67 and this procedure is written as the drive would
be delivered from the factory.
STEP 1:
(required) Ensure the control signals B2, B4, B5, and B6 are DISCONNECTED. (Drive modes will not change if these control signals are connected).
STEP 2:
Wire the mains and motor, and power the drive (See Figure 1).
STEP 3:
Use the
MODE key in combination with the
M
and ramp values. (See front cover of the VFD67 drive for parameter descriptions).
STEP 4:
Set Pr 05 to PAd (default setting).
STEP 5:
Set Pr 06 to motor rated current.
STEP 6:
Press the
MODE key button (2 times) on the keypad until
M
STEP 7:
Close or jumper terminal B2 to B4. (See Figure 2). Display will change from
STEP 8:
Press the green
START key on the drive keypad to run the drive (The display will read
STEP 9:
Press the
UP key to increase the speed, press the
drive.
2
Operate the VFD67 drive with a 0 to 10Vdc control signal
STEP 1:
(required) Ensure the control signals B2, B4, B5, and B6 are DISCONNECTED. (Drive modes will not change if these control signals are connected).
STEP 2:
Wire the mains and motor, and power the drive (See Figure 1).
STEP 3:
Use the
MODE key in combination with the
M
and ramp values. (See front cover of the VFD67 drive for parameter descriptions).
STEP 4:
Set Pr 05 to
STEP 5:
Set Pr 06 to motor rated current.
STEP 6:
Wire the control terminals (See Figure 3).
3
Operate the VFD67 drive with a 4-20mA control signal
STEP 1:
(required) Ensure the control signals B2, B4, B5, and B6 are DISCONNECTED. (Drive modes will not change if these control signals are connected).
STEP 2:
Wire the mains and motor, and power the drive (See Figure 1).
STEP 3:
Use the
MODE key in combination with the
M
and ramp values. (See front cover of the VFD67 drive for parameter descriptions).
STEP 4:
Set Pr 05 to
STEP 5:
Set Pr 06 to motor rated current.
STEP 6:
Wire the control terminals (See Figure 4).
VFD67 Quick Start Commissioning:
UP and
DOWN key to decrease the speed. The
UP and
(this is the analog voltage mode).
UP and
(this is the analog current mode).
www.johnsoncontrols.com
DOWN keys on the keypad to set parameters 1 to 4 for the desired frequency limits
is displayed.
DOWN keys on the keypad to set parameters 1 to 4 for the desired frequency limits
DOWN keys on the keypad to set parameters 1 to 4 for the desired frequency limits
to
and the motor will be at zero speed).
STOP/RESET key is used to stop and reset the
24-10511-7
