Create Alarm Attribute File - Siemens SINUMERIK 840D sl Commissioning Manual

If you want to add further alarm and message colors later, use the already created alarm
attribute file and proceed as described in Section: Insert alarm colors
If you want to add further alarm attribute files later, follow the procedure as of Section:
Complete configuration file
Procedure

1. Create alarm attribute file.

2. Insert alarm colors.
3. Create configuration file.
4. Complete configuration file.
5. Convert configuration file.
14.4.2 Create alarm attribute file
Create alarm attribute file with HMI sl
1. Copy the sample alarm attribute file "oem_slaedatabase.xml" from the directory
2. Store the file in the /OEM/sinumerik/hmi/cfg/ or /User/sinumerik/hmi/cfg/ directory.
3. Assign a unique name to the file, e.g. " muster_slaedatabase.xml ".
● Any name can be chosen but it must be written in lower case.
● The name must contain a period and file extension.
Create alarm attribute file on PC
You can also create the alarm attribute file externally on a PC.
Editing a file externally (Page 16)
HMI sl (IM9)
Commissioning Manual, 01/2008, 6FC5397-1DP10-3BA0
/Siemens/sinumerik/hmi/cfg
Note the following when assigning a name:
Configuring alarms
14.4 Changing alarm colors
135
