SC2000 Series Vision Sensor User Manual
Figure 8-37 Format Tool

8.4.10 Logic Tool

This tool allows you to select different logical operation types and execute logic operation. Go to
Solution → Output → Logic Tool → Logic, and double click Logic to open it.
Select AND, OR, NOT, NAND or NOR as Logical Operation Type, and click to link data source
or enter data directly.
You can also click to add multiple data.
Note
If there is logic module in the solution, you can go to Solution → Finish → Result to link the result
of logic tool to the solution.
56
