Result Display
In Image Display, click
edit OK color, NG color, and transparency.
8.4.3 Find Circle
This tool detects multiple edge points first, and then fits them into a circle. It is used to locate and
measure the circle.
Image Source
By default, the image source is the images acquired by the device.
Shape
You can use
to maximize the ROI (Region of Interest), or use
Note
● Before drawing ROI, you need to stop solution operation.
● After drawing ROI, you need to click Apply.
SC2000 Series Vision Sensor User Manual
Figure 8-18 Fixture Settings
to display or not display running point and reference point. Click
Figure 8-19 Result Display
36
to draw the ROI.
to
