8.4.4 Find Line
This tool finds a line with certain features in the image, and it uses known feature points to form
feature point group, and then fits into a line.
Image Source
By default, the image source is the images acquired by the device.
Shape
You can use
to maximize the ROI (Region of Interest), or use
Note
● Before drawing ROI, you need to stop solution operation.
● After drawing ROI, you need to click Apply.
● The ROI can be rectangle only.
Fixture
After enabling it, you can subscribe fixture tool. See Fixture Settings for details.
SC2000 Series Vision Sensor User Manual
Figure 8-22 Result Display
40
to draw the ROI.
