No.
5
Image Display
The solution setting module is used to configure different solutions.
No.
1
Solution Control
2
Solution Settings
3
Image Display
4
Operation History
5
Time Calculation
The system module is used to set system parameters. This module includes user management,
time synchronization, firmware upgrade, restoring factory settings, log, about and help.
SC2000 Series Vision Sensor User Manual
Area Name
Figure 7-4 Solution Setting Module
Table 7-2 Description of Solution Setting Module
Area Name
It is used to control solution, and display solution
operation result.
It is used to set up solution. It includes Camera, Tool,
Output and Finish.
It is used to display the operation result after executing
current solution.
It is used to display module operation result. Only recent
10 history results are displayed.
It is used to calculate and display the time cost by
algorithm, flow and tool respectively.
It is used to display the operation result after
executing current solution.
Description
19
Description
