3.1 17-Pin Interface

Read the following section to get definitions of 17-pin interface.
No.
1 POWER_IN
2 I/O_1
3 DO_2
4 RS232TX
5 RS232RX
6 MDI0+
7 MDI1-
8 DO_0
9 I/O_0
10 DO_1
11 GND
12 Reserved
13 I/O_2
14 MDI0-
15 MDI1+
SC2000 Series Vision Sensor User Manual

Chapter 3 Interface Description

Figure 3-1 17-Pin Interface
Table 3-1 Pin Definitions
Signal I/O Signal Source
--
Line 3 signal line
Line 7 signal line
--
--
--
--
Line 5 signal line
Line 2 signal line
Line 6 signal line
Signal ground
Line 4 signal line
--
--
Direct current power supply positive
Can be configured as input or output
Opto-isolated output
RS232 serial port output
RS232 serial port input
Fast Ethernet signal MDI0+
Fast Ethernet signal MDI1-
Opto-isolated output
Can be configured as input or output
Opto-isolated output
Direct current power supply
negative
Can be configured as input or output
Fast Ethernet signal MDI0-
Fast Ethernet signal MDI1+
4
Description
