8.4.7 Blob
Blob analysis means that the process of detecting, locating, or analyzing the target object in an
image region where the pixel is a finite grayscale. The Blob analysis tool provides certain features
of the target object in the image, such as presence, quantity, position, shape, direction, and
topological relation between Blobs.
Image Source
By default, the image source is the images acquired by the device.
Shape
You can use
to maximize the ROI (Region of Interest), or use
Note
● Before drawing ROI, you need to stop solution operation.
● After drawing ROI, you need to click Apply.
● The ROI can be rectangle only.
Fixture
After enabling it, you can subscribe fixture tool. See Fixture Settings for details.
SC2000 Series Vision Sensor User Manual
Figure 8-30 Result Display
49
to draw the ROI.
