Note
If you want to use fixture tool in blob, you should set fixture tool first.
Parameter Settings
Threshold Method
When the input image is a binary image, it is optional to not execute binarization. In other cases,
there are 4 options, including No Binarization, Single Threshold, Double Threshold, and Auto
Threshold.
Polarity
It has 2 modes, including Darker than Background, and Brighter than Background. Darker than
Background means that the feature image pixel value is lower than the background pixel value.
Brighter than Background means that the feature image pixel value is higher than the
background pixel value.
Note
This parameter takes effect when selecting Single Threshold or Auto Threshold as Threshold
Method.
Searching Quantity
It searches the quantity of Blob image.
SC2000 Series Vision Sensor User Manual
Figure 8-31 Blob
50
