5.1 Installation Preparation
You need to prepare following accessories before installation.
No.
Name
1
17-Pin Cable
Power Adapter or
2
Switch Power Supply
3
Lens Cap
4
Light Source
5
M4 Screw
5.2 Install Device
Before You Start
● Make sure the device in the package is in good condition and all the assembly parts are
included.
● Make sure all the related equipment is power-off during the installation.
Steps
1. Use M4 screw to fix the device to the installation position.
2. Connect the device to a power adapter or switch power supply via 17-pin cable.
3. Connect the device to a switch via network cable.
SC2000 Series Vision Sensor User Manual
Chapter 5 Installation
Table 5-1 Accessories
Quantity
1
1
1
1
4
It refers to the supplied 17-pin cable that is
included in the package.
You should select suitable power adapter or
switch power supply according to the device
power supply and consumption. You need to
purchase separately.
It refers to the supplied lens cap. You can
also use polarization lens cap that needs to
be purchased separately.
It refers to the supplied white light source.
You can also use red or blue light source that
needs to be purchased separately.
It refers to the supplied M4 screw that is
used to fix the device to installation position.
13
