Figure 8-36 Result Display
8.4.9 Format Tool
This tool is used to integrate and format data, and output string at last. Go to Solution → Output
→ Logic Tool → Format, and double click Format to open it.
In basic parameter interface, click
to subscribe data that is needed formatting or enter it
directly, and then click OK.
Note
● The max. byte allowed for formatting is 1024 bytes.
● When configuring multiple data, if one of data cannot be obtained, format exception may occur.
In display interface, enable Display Test to set text's color, front size, transparency, position X, and
position Y.
55
