5
Light Source
6
Screw
7
Screw Hole
8
PWR Indicator
9
STS Indicator
10
LNK Indicator
11
Button
SC2000 Series Vision Sensor User Manual
Name
The device has 8 LED lamps providing light, and you can
select wide-angle or spotlight lamps. White, red or blue
lamp is optional.
It refers to the screw between device body and lens
cap.
It is used to fix the device to installation position. You
should use M4 screw.
It is the power indicator. The indicator is green when
the device operates normally. Otherwise, it is red.
It is the status indicator. The indicator is green when
the solution operates normally. Otherwise, it is red.
It is network status indicator. The indicator is flashing
green when the network transmission is normal.
Otherwise, it is unlit.
It is used to trigger device solution operation.
Description
