Table 5-13 MVME721 Host I/O Connector (J10) Pin Assignments (continued)
Pin
41
43
45
47
49
51
53
55
57
59
61
63
5.2.8

Planar SATA Power Connector (J30)

There is one 2mm pitch header installed as a planar header on the MVME3100 board to
provide power to a serial ATA (SATA) drive mounted on the board or somewhere within the
chassis. The pin assignments for this header are as follows:

Table 5-14 Planar ATA Power Connector (J30) Pin Assignments

Pin
1
2
3
4
MVME3100 Single Board Computer Installation and Use (6806800M28H)
Signal
No Connect
No Connect
GND
No Connect
No Connect
No Connect
+5V
No Connect
No Connect
No Connect
No Connect
No Connect
Signal
+5V
+5V
GND
GND
Planar SATA Power Connector (J30)
Signal
+3.3V
No Connect
No Connect
No Connect
GND
No Connect
No Connect
No Connect
+3.3V
No Connect
No Connect
No Connect
Pin
42
44
46
48
50
52
54
56
58
60
62
64
