PCI Mezzanine Card (PMC) Connectors (J11 – J14, J21 – J23)
Table 5-3
Pin
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
82
PMC Slot 1 Connector (J11) Pin Assignments (continued)
Signal
PMCPRSNT1#
INTD#
GND
CLK
GND
PMCREQ1#
+3.3V (VIO)
AD28
AD25
GND
AD22
AD19
+3.3V (VIO)
FRAME#
GND
DEVSEL#
GND
PCI_RSVD
PAR
+3.3V (VIO)
AD12
AD09
GND
AD06
MVME3100 Single Board Computer Installation and Use (6806800M28H)
Signal
+5V
PCI_RSVD
+3.3Vaux
GND
PMCGNT1#
+5V
AD31
AD27
GND
C/BE3#
AD21
+5V
AD17
GND
IRDY#
+5V
LOCK#
PCI_RSVD
GND
AD15
AD11
+5V
C/BE0#
AD05
Pin Assignments
Pin
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
