MVME721 PMC I/O Module (PIM) Connectors (J10, J14)

5.2.7 MVME721 PMC I/O Module (PIM) Connectors (J10, J14)
PMC Host I/O connector J10 routes only power and ground from VME P2. There are no
Host I/O signals on this connector. The MVME3100 routes PMC I/O from J14 of PMC Slot
1 to VME P2 rows A and C. The MVME721 routes these signals (pin-for-pin) from VME P2
to PMC I/O Module connector J14. See

Table 5-13 MVME721 Host I/O Connector (J10) Pin Assignments

Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
96
Signal
No Connect
No Connect
+5V
No Connect
No Connect
No Connect
GND
No Connect
No Connect
No Connect
+5V
No Connect
No Connect
No Connect
GND
No Connect
No Connect
No Connect
+5V
No Connect
MVME3100 Single Board Computer Installation and Use (6806800M28H)
Table 5-13 and Table 5-6
Signal
No Connect
No Connect
No Connect
No Connect
+3.3V
No Connect
No Connect
No Connect
GND
No Connect
No Connect
No Connect
+3.3V
No Connect
No Connect
No Connect
GND
No Connect
No Connect
No Connect
Pin Assignments
for the pin assignments.
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
