Connecting to Peripherals

Damage of Circuits
Electrostatic discharge and incorrect installation and removal of the product can
damage circuits or shorten their life.
Before touching the product make sure that your are working in an ESD-safe
environment or wear an ESD wrist strap or ESD shoes. Hold the product by its edges
and do not touch any components or circuits.
Product Malfunction
Switches marked as Reserved might carry production-related functions and can
cause the product to malfunction if their setting is changed.
Do not change settings of switches marked as reserved.
Procedure
Use the following steps to install the MVME3100 into your computer chassis.
1. Attach an ESD strap to your wrist. Attach the other end of the ESD strap to an electrical
ground (refer to
and to ground throughout the procedure.
2. Remove any filler panel that might fill that slot.
3. Install the top and bottom edge of the MVME3100 into the guides of the chassis.
4. Ensure that the levers of the two injector/ejectors are in the outward position.
5. Slide the MVME3100 into the chassis until resistance is felt.
6. Simultaneously move the injector/ejector levers in an inward direction.
7. Verify that the MVME3100 is properly seated and secure it to the chassis using the two
screws located adjacent to the injector/ejector levers.
8. Connect the appropriate cables to the MVME3100.
9. To remove the board from the chassis, press the red locking tabs (IEEE handles only)
and reverse the procedure.
1.6 Connecting to Peripherals
When the MVME3100 is installed in a chassis, you are ready to connect peripherals and
apply power to the board.
32
Unpacking Guidelines). The ESD strap must be secured to your wrist
MVME3100 Single Board Computer Installation and Use (6806800M28H)
Hardware Preparation and Installation
