Unpacking Guidelines; Configuring Hardware; Table 1-1 Startup Overview - SMART Embedded Computing MVME3100 Installation And Use Manual

Unpacking Guidelines

Table 1-1
What you need to do...
Unpack the hardware.
Identify various components on the board.
Install the MVME3100 board in a chassis.
Connect any other equipment you will use.
Verify the hardware is installed.
1.3.2 Unpacking Guidelines
Unpack the equipment from the shipping carton. Refer to the packing list and verify that all
items are present. Save the packing material for storing and reshipping of equipment.
If the shipping carton is damaged upon receipt, request that the carrier's agent be present
during the unpacking and inspection of the equipment.
Damage of Circuits
Electrostatic discharge and incorrect installation and removal of the product can
damage circuits or shorten their life.
Before touching the product make sure that your are working in an ESD-safe
environment or wear an ESD wrist strap or ESD shoes. Hold the product by its edges
and do not touch any components or circuits.
1.4

Configuring Hardware

This section discusses certain hardware and software tasks that may need to be performed
prior to installing the board in a chassis.
To produce the desired configuration and ensure proper operation of the MVME3100, you
may need to carry out certain hardware modifications before installing the module.
Most options on the MVME3100 are software configurable. Configuration changes are
made by setting bits in control registers after the board is installed in a system.
Jumpers/switches are used to control those options that are not software configurable.
These jumper settings are described further on in this section. If you are resetting the board
jumpers from their default settings, it is important to verify that all settings are reset properly.
26
Startup Overview
MVME3100 Single Board Computer Installation and Use (6806800M28H)
Hardware Preparation and Installation
Refer to...
Unpacking Guidelines on page 26
MVME3100 Layout on page 27
Installing Hardware on page 31
Connecting to Peripherals on page 32
Completing the Installation on page 34
