Figure 1-1
them for you. Refer to
connectors listed below
Damage of the Product and Additional Devices and Modules
Incorrect installation or removal of additional devices or modules damages the
product or the additional devices or modules.
Before installing or removing additional devices or modules, read the respective
documentation and use appropriate tools.
Table 1-7
Connector
J4
J11, J12, J13, J14
J21, J22, J23
J24
J25
J27
J28
J29
J30
J41B
J41A
P1, P2
Table 1-8
Connector
J1A, J1B, J1C, J1D
J2A
J2B
MVME3100 Single Board Computer Installation and Use (6806800M28H)
shows the locations of the various connectors while
Chapter 5, Pin Assignments
MVME3100 Connectors
Function
PMC expansion connector
PCI mezzanine card (PMC) slot 1 connector
PCI mezzanine card (PMC) slot 2 connector
Boundary scan header
COP header
USB connector
Front panel SATA connector
Planar SATA connector
Planar SATA power connector
10/100/1000Mb/s Ethernet connector
COM port connector
VME backplane connectors
MVME721 Rear Transition Module Connectors
Function
COM port connectors
10/100/1000Mb/s Ethernet connector
10/100Mb/s Ethernet connector
Connecting to Peripherals
Table 1-7 and
for the pin assignments of the
Table 1-8 list
33
