SMART Embedded Computing MVME3100 Installation And Use Manual page 95

Table 5-11
Pin
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
MVME3100 Single Board Computer Installation and Use (6806800M28H)
VMEbus P1 Connector Pin Assignments (continued)
ROW Z ROW A
Reserved D06
GND D07
Reserved GND
GND SYSCLK
Reserved GND
GND DS1*
Reserved DS0*
GND WRITE*
Reserved GND
GND DTACK*
Reserved GND
GND AS*
Reserved GND
GND IACK*
Reserved IACKIN*
GND IACKOUT*
Reserved AM4
GND A07
Reserved A06
GND A05
Reserved A04
GND A03
Reserved A02
VMEbus P1 Connector
ROW B ROW C
BG1OUT* D14
BG2IN* D15
BG2OUT* GND
BG3IN* SYSFAIL*
BG3OUT* BERR*
BR0* SYSRESET*
BR1* LWORD*
BR2* AM5
BR3* A23
AM0 A22
AM1 A21
AM2 A20
AM3 A19
GND A18
SERA A17
SERB A16
GND A15
IRQ7* A14
IRQ6* A13
IRQ5* A12
IRQ4* A11
IRQ3* A10
IRQ2* A09
ROW D
Reserved
Reserved
GAP_L
GA0_L
GA1_L
Reserved
GA2_L
Reserved
GA3_L
Reserved
GA4_L
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
93
