PMC Expansion Connector (J4)
Table 5-1
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
78
PMC Expansion Connector Pin Assignment
Signal
+3.3V
PCICLK
GND
PURST#
HRESET#
TDO
TMS
TRST#
PCIXGNT#
+12V GND
PERR#
LOCK#
DEVSEL#
GND
TRDY#
STOP#
GND
ACK64#
REQ64#
MVME3100 Single Board Computer Installation and Use (6806800M28H)
Signal
+3.3V
PMCINTA#
PMCINTB#
PMCINTC#
PMCINTD#
TDI
TCK
PEP#
PCIXREQ#
-12V
SERR#
No Connect
No Connect
PCI XCAP
IRDY#
FRAME#
M66EN
No Connect
No Connect
Pin Assignments
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
