PCI Mezzanine Card (PMC) Connectors (J11 – J14, J21 – J23)
Table 5-5
Pin
57
59
61
63
Table 5-6
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
86
PMC Slot 1 Connector (J13) Pin Assignments (continued)
Signal
+3.3V (VIO)
Reserved
Reserved
GND
PMC Slot 1 Connector (J14) Pin Assignments
Signal
PMC1_1 (P2-C1)
PMC1_3 (P2-C2)
PMC1_5 (P2-C3)
PMC1_7 (P2-C4)
PMC1 _9 (P2-C5)
PMC1_11 (P2-C6)
PMC1_13 (P2-C7)
PMC1_15 (P2-C8)
PMC1_17 (P2-C9)
PMC1_19 (P2-C10)
PMC1PMC1_21 (P2-C11)
PMC1_23 (P2-C12)
PMC1_25 (P2-C13)
PMC1_27 (P2-C14)
PMC1_29 (P2-C15)
PMC1_31 (P2-C16)
PMC1_33 (P2-C17)
MVME3100 Single Board Computer Installation and Use (6806800M28H)
Signal
AD32
Reserved
GND
Reserved
Signal
PMC1_2 (P2-A1)
PMC1_4 (P2-A2)
PMC1_6 (P2-A3)
PMC1_8 (P2-A4)
PMC1_10 (P2-A5)
PMC1_12 (P2-A6)
PMC1_14 (P2-A7)
PMC1_16 (P2-A8)
PMC1_18 (P2-A9)
PMC1_20 (P2-A10)
PMC1_22 (P2-A11)
PMC1_24 (P2-A12)
PMC1_26 (P2-A13)
PMC1_28 (P2-A14)
PMC1_30 (P2-A15)
PMC1_32 (P2-A16)
PMC1_34 (P2-A17)
Pin Assignments
Pin
58
60
62
64
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
