Table 5-6
Pin
35
37
39
41
43
45
47
49
51
53
55
57
59
61
63
Table 5-7
Pin
1
3
5
7
9
11
MVME3100 Single Board Computer Installation and Use (6806800M28H)
PCI Mezzanine Card (PMC) Connectors (J11 – J14, J21 – J23)
PMC Slot 1 Connector (J14) Pin Assignments (continued)
Signal
PMC1_35 (P2-C18)
PMC1_37 (P2-C19)
PMC1_39 (P2-C20)
PMC1_41 (P2-C21)
PMC1_43 (P2-C22)
PMC1_45 (P2-C23)
PMC1_47 (P2-C24)
PMC1_49 (P2-C25)
PMC1_51 (P2-C26)
PMC1_53 (P2-C27)
PMC1_55 (P2-C28)
PMC1_57 (P2-C29)
PMC1_59 (P2-C30)
PMC1_61 (P2-C31)
PMC1_63 (P2-C32)
PMC Slot 2 Connector (J21) Pin Assignments
Signal
TCK
GND
INTD#
PMCPRSNT1#
INTB#
GND
Signal
PMC1_36 (P2-A18)
PMC1_38 (P2-A19)
PMC1_40 (P2-A20)
PMC1_42 (P2-A21)
PMC1_44 (P2-A22)
PMC1_46 (P2-A23)
PMC1_48 (P2-A24)
PMC1_50 (P2-A25)
PMC1_52 (P2-A26)
PMC1_54 (P2-A27)
PMC1_56 (P2-A28)
PMC1_58 (P2-A29)
PMC1_60 (P2-A30)
PMC1_62 (P2-A31)
PMC1_64 (P2-A32)
Signal
-12V
INTC#
INTA#
+5V
PCI_RSVD
+3.3Vaux
Pin
36
38
40
42
44
46
48
50
52
54
56
58
60
62
64
Pin
2
4
6
8
10
12
87
