Table 7-1
MPC8540
Signal
TSEC1_
TXD7
TSEC1_
TXD [6:4]
TSEC2_
TXD7
MVME3100 Single Board Computer Installation and Use (6806800M28H)
MPC8540 Power-on Reset Configuration Settings (continued)
Select Default
Option Setting
Resistor 0
Resistors 111
Resistor 0
MPC8540 Reset Configuration
Description State of Bit vs Function
0
TSEC1 Protocol
Configuration
1
000
001
011
Boot ROM
101
Location
110
111
0
TSEC2 Protocol
Configuration
1
1
TSEC1 controller uses
GMII protocol (RGMII
if TSEC1 configured in
reduced mode)
TSEC1 controller uses
TBI protocol (RTBI if
TSEC1 configured in
reduced mode)
PCI/PCI-X
DDR SDRAM
RapidIO
Local Bus GPCM
8-bit ROM
Local Bus GPCM
16-bit ROM
Local Bus GPCM
32-bit ROM
TSEC2 controller uses
GMII protocol (or
RGMII if TSEC2
configured in reduced
mode)
TSEC2 controller uses
TBI protocol (or RTBI
if TSEC2 configured in
reduced mode)
