Headers

This section describes the pin assignments of the Headers on the MVME3100. For Header
settings, refer to
5.3.1

Boundary Scan Header (J24)

The 14-pin boundary scan header provides an interface for programming the on-board
PLDs and for boundary scan testing/debug purposes. The pin assignments for this header
are as follows:

Table 5-17 Boundary Scan Header (J24) Pin Assignments

Pin
1
3
5
7
9
11
13
1. Pin 12 must be grounded in the cable in order to enable boundary scan.
5.3.2

Processor COP Header (J25)

There is one standard 16-pin header that provides access to the COP function. The pin
assignments for this header are as follows:

Table 5-18 Processor COP Header (J25) Pin Assignments

Pin
1
3
5
7
MVME3100 Single Board Computer Installation and Use (6806800M28H)
Configuring Hardware on page
Signal
TRST_L
TDO
TDI
TMS
TCK
NC
BSCAN_AW_L
Signal
CPU_TDO
CPU_TDI
Pull-up
CPU_TCK
26.
Signal
GND
GND
GND
GND
GND
GND (BSCANEN_L)
GND
Signal
No Connect
CPU_TRST_L
CPU_VIO (+3.3V)
CPU_CKSTPI_L
Headers
Pin
2
4
6
8
10
1
12
14
Pin
2
4
1
6
8
