USB Connector (J27)

5.2.9 USB Connector (J27)
There is one USB Type A connector located on the MVME3100 front panel. The pin
assignments are as follows:

Table 5-15 USB Connector (J27) Pin Assignments

Pin
1
2
3
4
5.2.10

SATA Connectors (J28 and J29)

The MVME3100 has two SATA connectors. J28 is an internal type SATA connector located
on the planar and is intended to connect to a drive located on the board or somewhere
inside the chassis. J29 is an external type SATA connected located on the front panel and
is intended to connect to an external SATA drive. The pin assignment for these connectors
is as follows:

Table 5-16 SATA Connectors (J28 and J29) Pin Assignments

Pin
1
2
3
4
5
6
7
98
Signal
USB_VBUS (+5.0V)
USB_DATA-
USB_DATA+
GND
Signal
GND
SATA_TX+
SATA_TX-
GND
SATA_RX-
SATA_RX+
GND
MVME3100 Single Board Computer Installation and Use (6806800M28H)
Pin Assignments
