Table 5-7
Pin
61
63
Table 5-8
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
MVME3100 Single Board Computer Installation and Use (6806800M28H)
PCI Mezzanine Card (PMC) Connectors (J11 – J14, J21 – J23)
PMC Slot 2 Connector (J21) Pin Assignments (continued)
Signal
AD00
GND
PMC Slot 2 Connector (J22) Pin Assignments
Signal
+12V
TMS
TDI
GND
Not Used
Pull-up
RST#
+3.3V
Not Used
AD30
GND
AD24
IDSEL1
+3.3V
AD18
AD16
GND
TRDY#
GND
Signal
+5V
REQ64#
Signal
TRST#
TDO
GND
Not Used
Not Used
+3.3V
Pull-down
Pull-down
GND
AD29
AD26
+3.3V
AD23
AD20
GND
C/BE2#
IDSEL1B
+3.3V
STOP#
Pin
62
64
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
