RTM SEEPROM Address Switch (S1)

A 4-position SMT configuration switch is located on the RTM to set the device address of
the RTM serial EEPROM device. The switch settings are defined in the following table.
Table 1-5
Position
Function
OFF
Table 1-6
Device Address
$A0
$A2
$A4
$A6
$A8
$AA (Factory)
$AC
$AE
The RTM EEPROM address switches must be set for address $AA in order for this device
to be accessible by MOTLoad.
1.5

Installing Hardware

Damage of the Product and Additional Devices and Modules
Incorrect installation or removal of additional devices or modules may damage the
product or the additional devices or modules.
Before installing or removing additional devices or modules, read the respective
documentation.
MVME3100 Single Board Computer Installation and Use (6806800M28H)
RTM EEPROM Address Switch Assignments
SW1
A0
1
EEPROM Address Settings
A(2:0)
000
001
010
011
100
101
110
111
RTM SEEPROM Address Switch (S1)
SW2 SW3
A1 A2
1 1
SW1 SW2
ON ON
OFF ON
ON OFF
OFF OFF
ON ON
OFF ON
ON OFF
OFF OFF
SW4
Not Used
SW3
ON
ON
ON
ON
OFF
OFF
OFF
OFF
