Hardware Preparation and Installation

1.1

Introduction

The MVME3100 is a single-slot, single board computer based on the MPC8540
PowerQUICC III™ integrated processor. The MVME3100 provides serial ATA (SATA), USB
2.0, 2eSST VMEbus interfaces, dual 64-bit/100MHz PMC sites, up to 128MB of flash, dual
10/100/1000 Ethernet, one 10/100 Ethernet, and five serial ports. This board supports front
and rear I/O and a single SODIMM module for DDR memory. Access to rear I/O is available
with the MVME721 rear transition module (RTM).
Front-panel connectors on the MVME3100 board include: one RJ-45 connector for the
Gigabit Ethernet, one RJ-45 connector for the asynchronous serial port, one USB port with
one type A connector, one SATA port with one external SATA connector, and a combined
reset and abort switch.
Rear-panel connectors on the MVME721 board include: one RJ-45 connector for each of
the 10/100 and 10/100/1000 BaseT Ethernets and four RJ-45 connectors for the
asynchronous serial ports. The RTM also provides two planar connectors for one PIM with
rear I/O.
1.2

Ordering and Support Information

Refer to the data sheets for the MVME3100 SBC for a complete list of available variants
and accessories. Refer to
local SMART Embedded Computing sales representative for the availability of other
variants.
For technical assistance, documentation, or to report product damage or shortages, contact
your local SMART EC sales representative or visit
https://www.smartembedded.com/ec/support/.
1.3

Getting Started

This section provides an overview of the steps necessary to install and power up the
MVME3100 and a brief section on unpacking and ESD precautions.
1.3.1

Overview of Startup Procedures

The following table lists the things you need to do before you can use this board and tells
where to find the information you need to perform each step. Be sure to read this entire
chapter, including all Caution and Warning notes, before you begin.
MVME3100 Single Board Computer Installation and Use (6806800M28H)
Appendix B, Related Documentation on page 143
Chapter 1
or consult your
25
