Figure 2-1 Front Panel Leds And Connectors - SMART Embedded Computing MVME3100 Installation And Use Manual

Switches and Indicators
Table 2-1
Function
GENET 1
Link / Speed
GENET 1
Activity

Figure 2-1 Front Panel LEDs and Connectors

SATA 1
COM 1
G ENET 1
36
Front-Panel LED Status Indicators (continued)
Label Color
Off
SPEED Yellow
Green
Blinking
Green
ACT
Off
PMC 2
PMC 1
ABORT/RESET
USER 1
FAIL
SPEED
ACT
MVME3100 Single Board Computer Installation and Use (6806800M28H)
Description
No link
10/100Base-T operation
1000Base-T operation
Activity proportional to bandwidth utilization.
No activity
Startup and Operation
