7.4

Local Bus Controller Chip Select Assignments

The following table shows local bus controller (LBC) bank and chip select assignments for
the MVME3100 board.
Table 7-3
LBC Bank/
Chip Select
0
1
2
3
4
5-7
1. Flash bank size determined by VPD flash packet.
2. Control/Status registers are byte read and write capable.
3. 32-bit timer registers are byte readable, but must be written as 32 bits.
7.5

Two-Wire Serial Interface

A two-wire serial interface for the MVME3100 is provided by an I
controller integrated into the MPC8540. The MPC8540 I
software to read the contents of the various I
following table contains the I
addresses.
Table 7-4
I2C Bus
Address
$90
$A0
MVME3100 Single Board Computer Installation and Use (6806800M28H)
Local Bus Controller Chip Select Assignments
LBC Chip Select Assignments
Local Bus Function
Boot Flash bank
Optional second Flash bank
Control/Status registers
Quad UART
32-bit timers
Not used
2
C devices used for the MVME3100 and their assigned device
I2C Bus Device Addressing
Device
Address
Size (bytes) Device Function
A2 A1 A0
(binary)
000 N/A
000 256 x 8
Data Bus
Size
Width
32MB - 128MB 32 bits
32MB - 128MB 32 bits
64 KB 32 bits
64 KB 8 bits
64 KB 32 bits
2
2
C controller is used by the system
2
C devices located on the MVME3100. The
DS1621 temperature sensor
DDR memory SPD (SODIMM module
banks 1 and 2 corresponding to
MPC8540 memory controller chip
selects 0 and 1)
Notes
1
1
2
3
C compatible serial
Notes
1
