Pin Assignments

5.1

Introduction

This chapter provides pin assignments for various connectors and headers on the
MMVE3100 single board computer and the MVME721 transition module.

PMC Expansion Connector (J4)

Ethernet Connectors (GENET1/J41B, GENET2/J2B, ENET1/J2A)
PCI Mezzanine Card (PMC) Connectors (J11 – J14, J21 – J23)
Serial Port Connectors (COM1/J41A, COM2–COM5/J2A-D)
VMEbus P1 Connector
VMEbus P2 Connector
MVME721 PMC I/O Module (PIM) Connectors (J10, J14)
Planar SATA Power Connector (J30)
USB Connector (J27)
SATA Connectors (J28 and J29)
The following headers are described in this chapter:
Boundary Scan Header (J24)
Processor COP Header (J25)
5.2

Connectors

This section describes the pin assignments and signals for the connectors on the
MVME3100.
5.2.1 PMC Expansion Connector (J4)
One 114-pin Mictor connector with a center row of power and ground pins is used to provide
PCI expansion capability. The pin assignments for this connector are as follows:
