Completing the Installation

Table 1-8
Connector
J10
J14
P2
1.7 Completing the Installation
Verify that hardware is installed and the power/peripheral cables connected are appropriate
for your system configuration.
Replace the chassis or system cover, reconnect the system to the AC or DC power source,
and turn the equipment power on.
34
MVME721 Rear Transition Module Connectors (continued)
Function
PIM power/ground
PIM I/O
VME backplane connector
