A Safety Advisories
Electrical and handling symbols
Electrical symbols
These can appear in instrument user manuals and on the instrument's front
or rear panels.
90
October 13, 2014, 715003547 Rev. C
Electrical power on
Electrical power off
Standby
Direct current
Alternating current
Protective conductor terminal
Frame, or chassis, terminal
Fuse
