Table B-29. PCI Configuration Space for Function 1
Address Name
0x01-0x00 Vendor ID
0x03-0x02 Device ID
0x05-0x04 Command Register
0x07-0x06 Status Register
0x08 Revision ID
0x0B-0x09 Class Code
0x0C Cache Line Size
0x0D Latency Timer
0x0E Header Type
0x0F BIST
0x13-0x10 Base Address 1
0x17-0x14 Base Address 2
0x1B-0x18 Base Address 3
0x1F-0x1C Base Address 4
ADSP-2192 DSP Peripheral Registers
Reset
0x11D4
0x219A
0x0
0x0
0x0
0x078000
0x0
0x0
0x80
0x0
0x08
0x08
0x08
0x01
ADSP-219x/2192 DSP Hardware Reference
Comments
Writable from the DSP during initial-
ization
Writable from the DSP during initial-
ization
Bus Master, Memory Space Capable,
I/O Space Capable
Bits enabled: Capabilities List, Fast
B2B, Medium Decode
Writable from the DSP during initial-
ization
Writable from the DSP during initial-
ization
Read-only
Read-only
Multifunction bit set
Unimplemented
Register Access for all ADSP-2192 Reg-
isters, Prefetchable Memory
24-bit DSP Memory Access
16-bit DSP Memory Access
I/O access for control registers and DSP
memory
B-63
