1. Kit Contents
The C8051T620 and C8051T622 Development Kits contain the following items:
 C8051T62x Motherboard
 C8051T62x Emulation Daughter Board with C8051F34A installed
 Socket Daughter Board (one of the following):
C8051T620DK: C8051T62x QFN 32-pin

C8051T622DK: C8051T622 QFN 24-pin

 Device samples (one of the following):
C8051T620DK: C8051T620-GM (Qty: 10) and C8051T626-B-GM (Qty: 10)

C8051T622DK: C8051T622-GM (Qty: 10)


C8051Txxx Development Kit Quick-Start Guide
Quick Start Guide includes steps to download the following development software and documentation (these

instructions can also be found in this document. See "4. Software Installation" on page 3.):
• Silicon Laboratories Integrated Development Environment (IDE)
• Evaluation version of 8051 development tools (macro assembler, linker, C compiler)
• Source code examples and register definition files
• Documentation
 AC-to-DC universal power adapter
 Two USB cables
2. About the Daughter Boards
The C8051T620 and C8051T622 Development Kits include an Emulation Daughter Board (EDB) and a QFN
Socket Daughter Board (QFN-DB). The EDB has an installed C8051F34A device, which is a Flash-based device
that can be used for the majority of C8051T62x/32x code development. The QFN-DB is intended to allow both
programming and system-level debugging of C8051T62x/32x devices directly.
A C8051T62x/32x device cannot be erased once it has been programmed; so, it is advisable to use the
C8051F34A for the majority of code development. Refer to "AN368: Differences between the C8051F34A and the
C8051T62x and C8051T32x Device Families" for more details on how the C8051F34A can be used to develop
code for the C8051T62x/32x device families. Application notes can be found on the Silicon Labs web site:
www.silabs.com/appnotes
