SFR Definition 29.7. PCA0CPLn: PCA Capture Module Low Byte

Bit 7
Name
Type R/W R/W
Reset 0
SFR Addresses: 0xFB (n = 0), 0xE9 (n = 1), 0xEB (n = 2), 0xED (n = 3), 0xFD (n = 4)
Bit Name
7:0 PCA0CPn[7:0] PCA Capture Module Low Byte.
The PCA0CPLn register holds the low byte (LSB) of the 16-bit capture module n.
This register address also allows access to the low byte of the corresponding
PCA channel's auto-reload value for 9, 10, or 11-bit PWM mode. The ARSEL bit
in register PCA0PWM controls which register is accessed.
Note: A write to this register will clear the module's ECOMn bit to a 0.

SFR Definition 29.8. PCA0CPHn: PCA Capture Module High Byte

Bit 7
Name
Type R/W R/W
Reset 0
SFR Addresses: 0xFC (n = 0), 0xEA (n = 1), 0xEC (n = 2), 0xEE (n = 3), 0xFE (n = 4)
Bit Name
7:0 PCA0CPn[15:8] PCA Capture Module High Byte.
The PCA0CPHn register holds the high byte (MSB) of the 16-bit capture module n.
This register address also allows access to the high byte of the corresponding
PCA channel's auto-reload value for 9, 10, or 11-bit PWM mode. The ARSEL bit in
register PCA0PWM controls which register is accessed.
Note: A write to this register will set the module's ECOMn bit to a 1.
C8051T620/1/6/7 & C8051T320/1/2/3
6 5 4
PCA0CPn[7:0]
R/W R/W
0 0 0
6 5 4
PCA0CPn[15:8]
R/W R/W
0 0 0
Rev. 1.2
3 2
R/W R/W
0 0
Function
3 2
R/W R/W
0 0
Function
1 0
R/W R/W
0 0
1 0
R/W R/W
0 0
287
