C8051T620/1/6/7 & C8051T320/1/2/3
USB Register Definition 23.8. POWER: USB0 Power
Bit 7
ISOUD
Name
R/W R/W
Type
0
Reset
USB Register Address = 0x01
Bit Name
7 ISOUD ISO Update Bit.
This bit affects all IN Isochronous endpoints.
0: When software writes INPRDY = 1, USB0 will send the packet when the next IN token
is received.
1: When software writes INPRDY = 1, USB0 will wait for a SOF token before sending the
packet. If an IN token is received before a SOF token, USB0 will send a zero-length data
packet.
6:5 Unused Read = 00b. Write = don't care.
4 USBINH USB0 Inhibit Bit.
This bit is set to 1 following a power-on reset (POR) or an asynchronous USB0 reset.
Software should clear this bit after all USB0 transceiver initialization is complete. Soft-
ware cannot set this bit to 1.
0: USB0 enabled.
1: USB0 inhibited. All USB traffic is ignored.
3 USBRST Reset Detect.
2 RESUME Force Resume.
Writing a 1 to this bit while in Suspend mode (SUSMD = 1) forces USB0 to generate
Resume signaling on the bus (a remote wakeup event). Software should write RESUME
= 0 after 10 to 15 ms to end the Resume signaling. An interrupt is generated, and hard-
ware clears SUSMD, when software writes RESUME = 0.
1 SUSMD Suspend Mode.
Set to 1 by hardware when USB0 enters suspend mode. Cleared by hardware when soft-
ware writes RESUME = 0 (following a remote wakeup) or reads the CMINT register after
detection of Resume signaling on the bus.
0: USB0 not in suspend mode.
1: USB0 in suspend mode.
0 SUSEN Suspend Detection Enable.
0: Suspend detection disabled. USB0 will ignore suspend signaling on the bus.
1: Suspend detection enabled. USB0 will enter suspend mode if it detects suspend sig-
naling on the bus.
174
6 5 4
USBINH
R/W R/W
0 0 1
Read:
0: Reset signaling is not present.
1: Reset signaling detected on
the bus.
Rev. 1.2
3 2
USBRST RESUME
R/W R/W
0 0
Function
Write:
Writing 1 to this bit forces an
asynchronous USB0 reset.
1 0
SUSMD SUSEN
R R/W
0 0
