Silicon Laboratories C8051T620 Manual page 177

USB Register Definition 23.12. OUT1INT: USB0 OUT Endpoint Interrupt
Bit 7
Name
R R
Type
0
Reset
USB Register Address = 0x04
Bit Name
7:4 Unused Read = 0000b. Write = don't care.
3 OUT3
OUT Endpoint 3 Interrupt-pending Flag.
This bit is cleared when software reads the OUT1INT register.
0: OUT Endpoint 3 interrupt inactive.
1: OUT Endpoint 3 interrupt active.
2 OUT2
OUT Endpoint 2 Interrupt-pending Flag.
This bit is cleared when software reads the OUT1INT register.
0: OUT Endpoint 2 interrupt inactive.
1: OUT Endpoint 2 interrupt active.
1 OUT1
OUT Endpoint 1 Interrupt-pending Flag.
This bit is cleared when software reads the OUT1INT register.
0: OUT Endpoint 1 interrupt inactive.
1: OUT Endpoint 1 interrupt active.
0 Unused Read = 0b. Write = don't care.
C8051T620/1/6/7 & C8051T320/1/2/3
6 5 4
R R
0 0 0
Rev. 1.2
3 2
OUT3 OUT2
R R
0 0
Function
1 0
OUT1
R R
0 0
177
