C8051T620/1/6/7 & C8051T320/1/2/3

SFR Definition 25.1. SCON0: Serial Port 0 Control

Bit 7
Name S0MODE
R/W
Type
0
Reset
SFR Address = 0x98; Bit-Addressable
Bit Name
7 S0MODE Serial Port 0 Operation Mode.
Selects the UART0 Operation Mode.
0: 8-bit UART with Variable Baud Rate.
1: 9-bit UART with Variable Baud Rate.
6 Unused Read = 1b, Write = Don't Care.
5 MCE0 Multiprocessor Communication Enable.
The function of this bit is dependent on the Serial Port 0 Operation Mode:
Mode 0: Checks for valid stop bit.
0: Logic level of stop bit is ignored.
1: RI0 will only be activated if stop bit is logic level 1.
Mode 1: Multiprocessor Communications Enable.
0: Logic level of ninth bit is ignored.
1: RI0 is set and an interrupt is generated only when the ninth bit is logic 1.
4 REN0 Receive Enable.
0: UART0 reception disabled.
1: UART0 reception enabled.
3 TB80 Ninth Transmission Bit.
The logic level of this bit will be sent as the ninth transmission bit in 9-bit UART Mode
(Mode 1). Unused in 8-bit mode (Mode 0).
2 RB80 Ninth Receive Bit.
RB80 is assigned the value of the STOP bit in Mode 0; it is assigned the value of the
9th data bit in Mode 1.
1 TI0 Transmit Interrupt Flag.
Set by hardware when a byte of data has been transmitted by UART0 (after the 8th bit
in 8-bit UART Mode, or at the beginning of the STOP bit in 9-bit UART Mode). When
the UART0 interrupt is enabled, setting this bit causes the CPU to vector to the UART0
interrupt service routine. This bit must be cleared manually by software.
0 RI0 Receive Interrupt Flag.
Set to 1 by hardware when a byte of data has been received by UART0 (set at the
STOP bit sampling time). When the UART0 interrupt is enabled, setting this bit to 1
causes the CPU to vector to the UART0 interrupt service routine. This bit must be
cleared manually by software.
220
6 5 4
MCE0 REN0
R R/W R/W
1 0 0
Rev. 1.2
3 2
TB80 RB80
R/W R/W
0 0
Function
1 0
TI0 RI0
R/W R/W
0 0
